•2 x 6 control outputs für HTL / PNP signals

•Pulse inputs with format A, /A, B, /B, Z, /Z [RS422]

•Input frequency up to 1 MHz

•2 encoder outputs, short-circuit-proof [TTL / RS422]

•Power supply 12 ... 30 VDC

•Current consumption (unloaded) 30 mA

•Encoder supply 5 ... 35 VDC (extern connect to +VAUX)

•Operation temperature: 0 ... 60 °C (32 ... 140°F)

•Latency time < 250ns

•Channel switching  < 1 ms

•Open plastic housing for top hat rail (according to EN 60715)

•LEDs for indication of the input pulses
